3 Phase 4 Wire 63A Automatic Transfer Switch, LED Display Generator and Inverter Voltage Protector, Flame Retardant PC Material, for Electric System (AC110V)
Size:
AC110V
En stock
0.47 kg
No
Nuevo
Amazon
USA
- Spec: Item Type: Automatic Transfer Switch Material: Flame Retardant PC Power Terminals: N, L1, L2, L3 Automatic Reclosure Delay (Ton): 1-600s Return Priority Phase Delay: 1-600s Switching Delay to Reserve Phase: Voltage Lag: 5V Overvoltage Trip Delay: 0.1s; ≥350V: 0.02s Undervoltage Trip Delay: 0.1s; ≥350V: 0.02s Voltage Accuracy: Maximum Working Phase Voltage: 350V Rated Working Current: 63A Maximum Working Current: 80A Pollution Grade: 3 Altitude: ≤2000m Ambient Temperature: -25-50℃ Relative Humidity: ≤50% at 40℃ (non condensing) Applicable Wire Size: 0.5mm²-1mm² Installation: 35mm Standard Rail Size: Approx. 90 x 66 x 95mm / 3.5 x 2.6 x 3.7in Package List: 1 x Automatic Transfer Switch 1 x User Manual How To Use: Follow the user manual to operate.
IMPORT EASILY
By purchasing this product you can deduct VAT with your RUT number
Conoce más detalles
[Wide Application] Ideal for continuous and stable power supply needs in various settings including commercial buildings, medical facilities, data centers, and base stations. [ & Design] Made of fireproof pc material, this automatic transfer switch offers high sensitivity, accurate measurement, and low heat generation for secure usage. [Priority Settings for Mains, Generators & Inverters] This 3 phase ats allows you to prioritize power sources with customizable voltage thresholds for automatic switching during over/undervoltage. [Stable Switching for ] Prevent power fluctuations or interference with adjustable parameters for conversion time, reset time, overvoltage/undervoltage guards, and overcurrent . [Ensure Uninterrupted Power Supply] When the main power fails or voltage is abnormal, this automatic transfer switch seamlessly shifts the load to the backup power source and reverts back after main power is restored.
